LED LIGHT ASSEMBLY LINE
LED LIGHT ASSEMBLY LINE
images Send Inquiry
Request To Call Back

LED LIGHT ASSEMBLY LINE

Price 100 INR/ Piece

Get a Price/Quote
MOQ : 100 Pieces

LED LIGHT ASSEMBLY LINE Specification

  • Mounting Type
  • Floor-mounted modular system
  • Weight
  • Approximately 300-600 kg (depends on line length)
  • Usage & Applications
  • LED light manufacturing and assembly
  • Surface Finish
  • Epoxy powder coated
  • Pole Type
  • Fixed linear workstation
  • Thickness
  • 2 mm (frame steel sections)
  • Features
  • Adjustable conveyor speed, ESD-safe surface, integrated tools rails, LED illumination, operator seating, and material racks
  • Product Type
  • LED Light Assembly Line
  • Material
  • Mild steel with powder coating
  • Rated Power
  • 120 W
  • Length
  • 6 to 20 meters (customizable)
  • Voltage
  • 220-240 V AC
  • Lighting
  • Integrated LED task lights along the line
  • Input Voltage
  • 220 V AC
  • Working Temperature
  • 0C to 55C
  • Rated Current
  • 10 A (per socket)
  • Socket
  • Industrial modular sockets for tools
  • Color
  • Green/White workstation with Aluminum profiles
  • Height
  • 900-950 mm (worktop height)
  • Workstation Width
  • 600-750 mm
  • Illumination Intensity
  • 600-800 lux near workstation
  • Operator Capacity
  • 6 to 20 operators (configurable)
  • Power Supply
  • Single-phase 220-240 V / 50-60 Hz
  • Packaging Facilities
  • Integrated at the end of the assembly line
  • Assembly Table Material
  • Laminate/Epoxy work surface with ESD protection
  • Control Panel
  • Centralized control panel with start/stop, speed control, and indicator lights
  • Optional Accessories
  • Magnifying lamps, tool balancers, documentation holders, and monitor stands
  • Assembly Stations
  • Multiple workstations with individual power outlets and tool rails
  • Conveyor Type
  • Belt conveyor with soft start and adjustable speed
  • Noise Level
  • Below 70 dB during operation
  • Safety
  • Emergency stop switches and anti-static wrist strap points
  • Mobility
  • Adjustable feet for leveling, optional caster wheels
  • Conveyor Speed
  • 0-6 meters/minute, adjustable


LED LIGHT ASSEMBLY LINE Trade Information

  • Minimum Order Quantity
  • 100 Pieces
  • Supply Ability
  • 500 Pieces Per Month
  • Delivery Time
  • 7 Days


About LED LIGHT ASSEMBLY LINE

Founded in the year 2015, we "Acs Lighting Private Limited are a distinguished manufacturer and trader of a broad range of LED Light, DC Fan, High Beam Torch and DC Operated Lamp. We are a Sole Proprietorship firm that was incepted with an objective of providing best quality range of products. Situated at Rajkot (Gujarat, India), we have constructed a well-established infrastructural unit that plays a vital role in the growth of our company. Under the headship of "Mr. Anand Patel (Proprietor), we have gained huge client¨le across the nation.
